| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 418-925-4260 | Lock Assembly | 70291- | |
| 2 | 423-925-4760 | Clip | 70291- | |
| 3 | 418-926-3913 | Cover | 72281- | |
| 3 | 417-926-3470 | Button | 70291- | |
| 3 | 09415-01008 | Cap | 70291- | |
| 4 | 01225-70616 | Screw, Philips Head | 70291- | |
| 5 | 418-926-3490 | Washer | 70291- | |
| 6 | 08037-01008 | Grommet | 70291- | |
| 7 | 14X-911-1540 | Knob | 70291- | |
| 8 | 205-54-72220 | Handle | 70291- | |
| 9 | 417-926-3250 | Screw | 70291- | |
| 10 | 01643-51032 | Washer | 72281- | |
| 11 | 417-926-3380 | Lock Assembly | 70291- | |
| 12 | 01010-80820 | Bolt | 70291- | |
| 13 | 01643-30823 | Washer | 70291- | |
| 14 | 421-56-21720 | Cap | 70291- | |
| 15 | 418-925-4220 | Handle | 70291- | |
| 16 | 01010-80616 | Bolt | 70291- | |
| 17 | 01643-30623 | Washer | 70291- | |
| 18 | 01643-30623 | Washer | 70291- | |
| 19 | 418-925-4310 | Rod | 70291- | |
| 20 | 04052-10633 | Pin, Snap | 70291- | |
| 21 | 418-925-4320 | Rod | 70291- | |
| 22 | 424-926-3261 | Handle | 70291- | |
| 23 | 424-925-3260 | Clip | 72308- | |
| 24 | 01010-80616 | Bolt | 70291- | |
| 25 | 01643-30623 | Washer | 70291- | |
| 26 | 424-926-3630 | Grommet | 70291- | |
| 27 | 423-926-3860 | Grommet | 70291- | |
| 28 | 417-926-3431 | Sheet | 71444- | |
| 29 | 426-925-3380 | Seal | 70291- | |
| 30 | 417-923-3950 | Stopper | 70291- | |
| 31 | 01010-81025 | Bolt | 70291- | |
| 32 | 01643-31032 | Washer | 70291- | |
| 33 | 418-926-3760 | Bracket | 70291- | |
| 34 | 01010-D1025 | Bolt | 70291- | |
| 35 | 01643-71032 | Washer | 70291- | |
| 36 | 20Y-54-35710 | Plate | 70291- | |
| 37 | 20Y-54-35961 | Striker | 70291- | |
| 38 | 01643-31032 | Washer | 70291- | |
| 39 | 20T-54-75290 | Stopper | 70291- | |
| 40 | 01580-11008 | Nut | 70291- | |
| 41 | 20Y-53-11810 | Striker | 70291- | |
| 42 | 20Y-54-35480 | Shim, T=1.6mm | 70291- | |
| 43 | 01240-01025 | Screw | 70291- | |
| 44 | 21N-54-35P80 | Plate | 70291- |
