| Item | Part No. | Part Name | Qty | Serial No. |
| (144-13-00300) | TORQUE CONVERTER A. (TCS38-1H) | 46890- | ||
| THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.9231 TO 9234. | ||||
| 1 | 144-13-14111 | GEAR | 46890- | |
| 2 | 06030-05206 | BEARING | 46890- | |
| 3 | 04064-03015 | RING,SNAP | 46890- | |
| 4 | 175-13-23500 | PUMP ASS'Y | 46890- | |
| 4 | 175-13-23540 | COVER | 46890- | |
| 5 | 175-13-23510 | GEAR ASS'Y,DRIVE | 46890- | |
| 6 | 175-13-23520 | GEAR ASS'Y,DRIVEN | 46890- | |
| 7 | 175-13-23530 | CASE | 46890- | |
| 7A | 01190-01011 | HELISERT | 46890- | |
| 8 | 04020-00820 | PIN | 46890- | |
| 9 | 01010-50835 | BOLT | 46890- | |
| 10 | 01602-20825 | WASHER,SPRING | 46890- | |
| 10A | 01641-20812 | WASHER | 46890- | |
| 11 | 07000-62115 | O-RING (K1) | 46890- | |
| 12 | 01010-51235 | BOLT | 46890- | |
| 13 | 01602-21236 | WASHER,SPRING | 46890- | |
| 14 | 01641-21223 | WASHER | 46890- |
