| Item | Part No. | Part Name | Qty | Serial No. |
| (273-950-0012) | OPERATOR'S CAB ASS'Y | 30046- | ||
| (273-950-0011) | OPERATOR'S CAB ASS'Y | 30003-30045 | ||
| THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.5441 TO 5459. | ||||
| 1 | 273-950-1270 | SEAT | 30003- | |
| 2 | 273-950-1280 | BRACKET | 30003- | |
| 3 | 01010-51030 | BOLT | 30003- | |
| 4 | 01643-31032 | WASHER | 30003- | |
| 5 | 01643-31032 | WASHER | 30003- | |
| 6 | 01010-51025 | BOLT | 30003- | |
| 7 | 01010-51030 | BOLT | 30003- | |
| 8 | 01580-11008 | NUT | 30003- | |
| 9 | 01643-31032 | WASHER | 30003- | |
| 10 | 01643-31032 | WASHER | 30003- | |
| 11 | 273-950-1190 | SUPPORT | 30003- | |
| 12 | 09415-02512 | CAP | 30003- | |
| 13 | 273-43-16120 | COVER | 30046- | |
| 14 | 273-43-16130 | PLATE | 30046- | |
| 15 | 01010-50820 | BOLT | 30046- | |
| 16 | 01643-30823 | WASHER | 30046- | |
| 17 | 237-54-11270 | CUSHION | 30046- |
