| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 569-40-11310 | ARM,L.H. | 1002-1068 | |
| 569-40-11320 | ARM,R.H. | 1002-1068 | ||
| 2 | 569-40-11350 | PLATE | 1002-1068 | |
| 3 | 281-22-12921 | PLATE | 1002-@ | |
| 4 | 01010-81640 | BOLT | 1002-1068 | |
| 5 | 569-40-11370 | BUSHING | 1002-@ | |
| 6 | 07000-02085 | O-RING | 1002-@ | |
| 7 | 07137-05509 | BUSHING | 1002-@ | |
| 8 | 04071-00125 | RING | 1002-@ | |
| 9 | 07000-02055 | O-RING | 1002-@ | |
| 10 | 04082-00212 | LOCK | 1002-@ | |
| 11 | 01010-51225 | BOLT | 1002-@ | |
| 12 | 01602-21236 | WASHER | 1002-@ | |
| 13 | 569-40-11330 | PIN | 1002-@ | |
| 14 | 07020-00000 | FITTING | 1002-@ | |
| 15 | 569-40-11340 | PIN | 1002-1068 | |
| 16 | 569-40-11360 | PLATE | 1002-1068 | |
| 17 | 01010-51640 | BOLT | 1002-@ | |
| 18 | 568-40-11330 | LOCK | 1002-@ | |
| 19 | 01011-53060 | BOLT | 1002-1068 | |
| 20 | 01643-33080 | WASHER | 1002-1068 | |
| 21 | 569-40-11220 | PIN | 1002-1068 | |
| 22 | 07020-00675 | FITTING | 1002-@ | |
| 23 | 04082-00212 | LOCK | 1002-@ | |
| 24 | 01010-51225 | BOLT | 1002-@ | |
| 25 | 01602-21236 | WASHER | 1002-@ | |
| 26 | 569-40-11211 | ROD | 1002-1068 | |
| 27 | 569-40-11230 | HEAD | 1002-1068 | |
| 28 | 569-40-11240 | HEAD | 1002-1068 | |
| 29 | 07137-04006 | BUSHING | 1002-@ | |
| 30 | 04065-09030 | RING | 1002-@ | |
| 31 | 07000-03040 | O-RING | 1002-@ | |
| 32 | 01010-51680 | BOLT | 1002-1068 | |
| 33 | 01580-11613 | NUT | 1002-1068 | |
| 34 | 01602-21648 | WASHER | 1002-1068 | |
| 35 | 569-40-11411 | LEVER | 1033-@ | |
| \0\569-40-11410 | LEVER | 1002-1032 | ||
| 36 | 569-40-11420 | BUSHING | 1002-@ | |
| 37 | 07145-00055 | SEAL | 1002-@ | |
| 38 | 569-40-11330 | PIN | 1002-@ | |
| 39 | 07020-00675 | FITTING | 1002-@ | |
| 40 | 566-43-15710 | NIPPLE | 1002-@ | |
| 41 | 04082-00212 | LOCK | 1002-@ | |
| 42 | 01010-51225 | BOLT | 1002-@ | |
| 43 | 01602-21236 | WASHER | 1002-@ | |
| 44 | 569-40-11220 | PIN | 1002-@ | |
| 45 | 04082-00212 | LOCK | 1002-@ | |
| 46 | 01010-51225 | BOLT | 1002-@ | |
| 47 | 01602-21236 | WASHER | 1002-@ | |
| 48 | 07020-00675 | FITTING | 1002-@ | |
| 49 | 569-52-11140 | PIN | 1002-@ | |
| 50 | 07020-00000 | FITTING | 1002-@ | |
| 51 | 01010-51430 | BOLT | 1002-1068 | |
| 52 | 01602-21442 | WASHER | 1002-@ | |
| 53 | 566-52-11150 | PLATE | 1002-1068 | |
| 54 | 569-52-11130 | SPACER | 1002-@ | |
| 55 | 569-40-11111 | LEVER | 1002-1068 | |
| 56 | 01010-82475 | BOLT | 1002-1068 | |
| 57 | 01602-22472 | WASHER | 1002-1068 | |
| 58 | 07049-03342 | PLUG | 1002-1068 |
