| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 427-40-21110 | BRACKET | 52001- | |
| 2 | 01435-01230 | BOLT | 52001- | |
| 3 | 426-S33-2130 | PLATE | 52001- | |
| 4 | 01252-40825 | BOLT | 52001- | |
| 5 | 01584-00806 | NUT | 52001- | |
| 6 | 01643-30823 | WASHER | 52001- |
- Главная
- Каталог запчастей
- Колесные погрузчики
- Wa800l 3 s/n 52001 up
- Operator's compartment and control system
- Steering control (linkage)
Поиск по каталогу
STEERING CONTROL (LINKAGE)
