| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 11Y-62-12120 | Nipple | 81020- | |
| 1 | 418-62-32110 | Nipple | 80001-81019 | |
| 2 | 416-62-11480 | O-ring | 80001- | |
| 3 | 417-62-51370 | Hose | 80001- | |
| 4 | 02896-11008 | O-ring | 80001- | |
| 5 | (02782-10210) | Elbow | - |
- Главная
- Каталог запчастей
- Колесные погрузчики
- Wa200 7 s/n 80001 up
- Hydraulic system
- Steering control valve, steering drain piping (#80001 )
Поиск по каталогу
Steering Control Valve, Steering Drain Piping (#80001-)
