| Item | Part No. | Part Name | Qty | Serial No. |
| 566-63-11300 | CYLINDER ASS'Y,L.H. | 1069- | ||
| 566-63-11100 | CYLINDER ASS'Y,L.H. | 1002-1068 | ||
| 566-63-11400 | CYLINDER ASS'Y,R.H. | 1069- | ||
| 566-63-11200 | CYLINDER ASS'Y,R.H. | 1002-1068 | ||
| 1 | 566-63-11310 | CYLINDER,L.H. | 1069- | |
| 566-63-11232 | CYLINDER,L.H. | 1002-1068 | ||
| 566-63-11310 | CYLINDER,R.H. | 1069- | ||
| 566-63-11131 | CYLINDER,R.H. | 1002-1068 | ||
| 2 | 07137-04006 | BUSHING | 1002- | |
| 3 | 07000-23040 | O-RING | 1002- | |
| 4 | 04065-09030 | RING | 1002- | |
| 5 | 566-63-11141 | ROD | 1069- | |
| 566-63-11140 | ROD | 1002-1068 | ||
| 6 | 07137-04006 | BUSHING | 1002- | |
| 7 | 07000-23040 | O-RING | 1002- | |
| 8 | 04065-09030 | RING | 1002- | |
| 9 | 566-63-11150 | HEAD | 1002- | |
| 10 | 07177-06030 | BUSHING | 1002- | |
| 11 | 707-51-60110 | PACKING | 1069- | |
| \0\111-63-22233 | PACKING | 1002-1068 | ||
| 12 | 566-63-11330 | GLAND | 1002- | |
| 13 | 07177-06015 | BUSHING | 1002- | |
| 14 | 144-63-93270 | SEAL | 1069- | |
| \0\07016-00608 | SEAL | 1002-1068 | ||
| 15 | 07000-23075 | O-RING | 1002- | |
| 16 | 01010-51450 | BOLT | 1002- | |
| 17 | 01602-21442 | WASHER | 1002- | |
| 18 | 07000-22095 | O-RING | 1002- | |
| 19 | 07146-02096 | RING | 1002- | |
| 20 | 566-63-11170 | PISTON | 1069- | |
| \0\281-63-13220 | PISTON | 1002-1068 | ||
| 21 | 07155-01025 | RING | 1002- | |
| 22 | 281-63-11230 | RING | 1069- | |
| 281-63-11230 | RING | 1002-1068 | ||
| 23 | 07165-13033 | NUT | 1002- | |
| 24 | 01010-51845 | BOLT | 1002- | |
| 25 | 01602-21854 | WASHER | 1002- | |
| 26 | 07179-00082 | RING | 1002- |
