| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-49-51120 | TUBE | 3001- | |
| 2 | 07000-02065 | O-RING | 3001- | |
| 3 | 01010-51235 | BOLT | 3001- | |
| 4 | 01602-21236 | WASHER,SPRING | 3001- | |
| 5 | 07260-05825 | HOSE | 3001- | |
| 6 | 07289-00070 | CLAMP | 3704- | |
| 6 | \0\205-09-61120 | CLAMP | 3057-3703 | |
| 6 | \0\208-09-11120 | CLAMP | 3001-3056 | |
| 7 | 154-49-51130 | TUBE | 3001- | |
| 8 | 07000-02060 | O-RING | 3001- | |
| 9 | 01010-51240 | BOLT | 3001- | |
| 10 | 01643-31232 | WASHER | 3001- | |
| 11 | 154-49-51141 | TUBE | 3001- | |
| 12 | 07000-03042 | O-RING | 3001- | |
| 13 | 01010-51240 | BOLT | 3001- | |
| 14 | 01643-31232 | WASHER | 3001- | |
| 15 | 07260-04120 | HOSE | 3001- | |
| 16 | 07289-00055 | CLAMP | 3704- | |
| 16 | \0\208-09-11110 | CLAMP,HOSE | 3001-3703 | |
| 17 | 154-49-51150 | TUBE | 3001- | |
| 18 | 07042-30108 | PLUG | 3001- | |
| 19 | 07000-03038 | O-RING | 3001- | |
| 20 | 01010-51035 | BOLT | 3001- | |
| 21 | 01010-51080 | BOLT | 3001- | |
| 22 | 01643-31032 | WASHER,SPRING | 3001- | |
| 23 | (07436-72202) | PUMP ASS'Y | 3001- | |
| 24 | 07000-02085 | O-RING | 3001- | |
| 25 | 01140-51255 | STUD | 3001- | |
| 26 | 01582-11210 | NUT | 3001- | |
| 27 | 01643-31232 | WASHER | 3001- | |
| 28 | 154-49-51231 | TUBE | 3102- | |
| 28 | \0\154-49-51230 | TUBE | 3001-3101 | |
| 29 | 07000-03025 | O-RING | 3001- | |
| 30 | 01010-51035 | BOLT | 3001- | |
| 31 | 01643-31032 | WASHER | 3001- | |
| 32 | 07102-20605 | HOSE | 3001- |
