| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07235-10628 | ELBOW | 1003- | |
| 1 | 07235-10628 | ELBOW | 1001-1002 | |
| 2 | 07235-10630 | ELBOW | 1003- | |
| 3 | 07002-22434 | O-RING | 1001- | |
| 4 | 04434-53412 | CLIP | 1001- | |
| 5 | 07095-20627 | CUSHION | 1001- | |
| 6 | 23S-62-25850 | CLIP | 1001- | |
| 7 | 01010-81220 | BOLT | 1001- | |
| 8 | 01643-31232 | WASHER | 1001- | |
| 9 | 04434-53412 | CLIP | 1001- | |
| 10 | 07095-20627 | CUSHION | 1001- | |
| 11 | 01010-81220 | BOLT | 1001- | |
| 12 | 01643-31232 | WASHER | 1001- |
