| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 07102-20671 | HOSE | 2001- | |
| 2 | 07102-20680 | HOSE | 2001- | |
| 3 | 285-02-11320 | CLIP | 2070- | |
| 285-02-11320 | CLIP | 2001-2069 | ||
| 4 | 566-61-49810 | INSULATOR | 2070- | |
| 566-61-49810 | INSULATOR | 2001-2069 | ||
| 5 | 01010-51016 | BOLT | 2001- | |
| 6 | 01643-31032 | WASHER | 2001- | |
| 7 | 01643-31232 | WASHER | 2001- | |
| 8 | 01010-51230 | BOLT | 2001- | |
| 9 | 582-35-11170 | CLIP | 2070- | |
| 582-35-11170 | CLIP | 2001-2069 | ||
| 10 | 566-06-41290 | INSULATOR | 2070- | |
| 566-06-41290 | INSULATOR | 2001-2069 | ||
| 11 | 01010-51016 | BOLT | 2001- | |
| 12 | 01643-31032 | WASHER | 2001- | |
| 13 | 01010-51225 | BOLT | 2001- | |
| 14 | 01643-31232 | WASHER | 2001- | |
| 15 | 01010-51020 | BOLT | 2001- | |
| 16 | 01643-31032 | WASHER | 2001- | |
| 17 | 561-61-63660 | PLATE | 2001- | |
| 18 | 07283-24354 | CLIP | 2001- | |
| 19 | 01643-31032 | WASHER | 2001- | |
| 20 | 01599-01011 | NUT | 2001- | |
| 21 | 569-54-41380 | PLATE | 2001- | |
| 22 | 07283-26155 | CLIP | 2001- | |
| 23 | 01599-01011 | NUT | 2001- | |
| 24 | 01643-31032 | WASHER | 2001- | |
| 25 | 561-61-63650 | PLATE | 2001- | |
| 26 | 01010-51025 | BOLT | 2001- | |
| 27 | 01643-31032 | WASHER | 2001- | |
| 28 | 562-61-24910 | COOLER | 2001- | |
| 29 | 01010-51025 | BOLT | 2001- | |
| 30 | 01643-31032 | WASHER | 2001- | |
| 31 | 07230-10628 | UNION | 2001- | |
| 32 | 07002-22434 | O-RING | 2001- | |
| 33 | 561-61-63670 | BRACKET | 2001- | |
| 34 | 01010-51245 | BOLT | 2001- | |
| 35 | 01643-31232 | WASHER | 2001- |
