| Item | Part No. | Part Name | Qty | Serial No. |
| 565-41-17303 | PUMP ASS'Y | 510- | ||
| (\2\565-41-17301) | PUMP ASS'Y | (510-1606) | ||
| 1 | 565-41-17310 | CARTRIDGE ASS'Y | 510- | |
| 5 | 565-41-17320 | PLATE,PRESSURE | 510- | |
| 6 | 565-41-17330 | PLATE,SIDE | 510- | |
| 7 | 565-41-17340 | PIN,STRAIGHT | 510- | |
| 8 | 565-41-17350 | BOLT | 510- | |
| 9 | 565-41-17360 | WASHER | 510- | |
| 10 | 565-41-17370 | WASHER | 510- | |
| 11 | 565-41-17380 | BODY ASS'Y | 510- | |
| 12 | 565-41-17392 | SHAFT ASS'Y,(SERVICE PARTS) | 1607- | |
| 12 | 565-41-17040 | SHAFT ASS'Y | 510-1606 | |
| 12 | (\2\565-41-17390) | SHAFT ASS'Y | (510-1606) | |
| 13 | 565-41-17410 | BEARING,NEEDLE | 510- | |
| 14 | 565-41-17420 | BEARING,BALL (KIT) | 510- | |
| 15 | 565-41-17430 | SEAL,OIL (KIT) | 510- | |
| 16 | 565-41-17441 | RING | 1607- | |
| 16 | 04064-02012 | RING | 510-1606 | |
| 16 | \0\565-41-17440 | RING | 510-1606 | |
| 17 | 04065-05220 | RING | .- | |
| 17 | \0\565-41-17450 | RING | 510-. | |
| 18 | 565-41-17460 | KEY | 510- | |
| 19 | 565-41-17470 | BODY ASS'Y | 510- | |
| 565-41-17030 | VALVE ASS'Y | 510- | ||
| 20 | 565-41-17480 | VALVE | 510- | |
| 21 | \6\ | VALVE | 510- | |
| 22 | \6\ | RETAINER | 510- | |
| 23 | \6\ | BALL | 510- | |
| 24 | \6\ | SPRING | 510- | |
| 25 | \6\ | SHIM | 510- | |
| 26 | 565-41-17550 | SPRING | 510- | |
| 27 | 565-41-17560 | PLUG | 510- | |
| 28 | 565-41-17570 | O-RING (KIT) | 510- | |
| 29 | 565-41-17580 | O-RING (KIT) | 510- | |
| 30 | 565-41-17590 | O-RING (KIT) | 510- | |
| 31 | 565-41-17610 | O-RING (KIT) | 510- | |
| 32 | 565-41-17620 | BOLT | 510- | |
| 33 | 565-41-17630 | WASHER | 510- | |
| 34 | 565-41-17640 | COLLAR | 510- | |
| 35 | 565-41-17650 | RESERVOIR | 510- | |
| 36 | 565-41-17660 | WASHER | 510- | |
| 37 | 565-41-17670 | WASHER | 510- | |
| 38 | 565-41-17680 | BOLT | 510- | |
| 39 | 565-41-17690 | PLATE ASS'Y | 510- | |
| 40 | 565-41-17710 | WASHER | 510- | |
| 41 | 565-41-17720 | BOLT | 510- | |
| 42 | 565-41-17730 | CONNECTOR | 510- | |
| 43 | 565-41-17740 | OIL FILTER ASS'Y | 510- | |
| 44 | 565-41-17750 | GASKET (KIT) | 510- | |
| 45 | 565-41-17760 | SPRING | 510- | |
| 46 | 565-41-17770 | OIL STRAINER ASS'Y | 510- | |
| 47 | 565-41-17780 | O-RING (KIT) | 510- | |
| 48 | 565-41-17790 | WASHER | 510- | |
| 49 | 565-41-17810 | CAP ASS'Y | 510- | |
| 50 | \6\ | CAP | 510- | |
| 51 | \6\ | CAP | 510- | |
| 52 | \6\ | CAP | 510- | |
| 53 | \6\ | CAP | 510- | |
| 54 | 565-41-17820 | BREATHER ASS'Y | 510- | |
| 55 | 565-41-17830 | LEVEL GAUGE ASS'Y | 510- | |
| 56 | 565-41-17840 | GASKET (KIT) | 510- | |
| 57 | 565-41-17850 | RETAINER | 510- | |
| 58 | 565-41-17860 | BOLT | 510- | |
| 59 | 565-41-17870 | PLUG | 510- | |
| 60 | 565-41-17880 | O-RING (KIT) | 510- | |
| 61 | 565-41-17890 | WASHER | 510- | |
| 62 | 565-41-17910 | NUT | 510- | |
| 63 | 565-41-17920 | WASHER | 510- | |
| 64 | 565-41-17930 | GASKET (KIT) | 510- |
