| Item | Part No. | Part Name | Qty | Serial No. |
| 267-70-10102 | ROLLER ASS'Y | 1157- | ||
| 267-70-10101 | ROLLER ASS'Y | 1101-1156 | ||
| 267-70-10100 | ROLLER ASS'Y | 1097-1100 | ||
| 267-70-10109 | ROLLER ASS'Y | 1047-1096 | ||
| 1 | 267-70-11332 | SHAFT | 1157- | |
| 267-70-11331 | SHAFT | 1101-1156 | ||
| 267-70-11330 | SHAFT | 1047-1100 | ||
| 2 | 267-98-12020 | KEY | 1101- | |
| 04000-01232 | KEY | 1047-1100 | ||
| 3 | 267-70-11202 | ROLLER | 1157- | |
| 267-70-11201 | ROLLER | 1047-1156 | ||
| 4 | 267-70-15311 | DRUM | 1157- | |
| 267-70-15310 | DRUM | 1047-1156 | ||
| 5 | 01040-31225 | BOLT | 1101- | |
| 267-70-15390 | BOLT | 1047-1100 | ||
| 6 | 267-70-15461 | WASHER | 1157- | |
| 267-70-15460 | WASHER | 1101-1156 | ||
| 7 | 01601-01648 | WASHER | 1047- | |
| 8 | 04059-01050 | WIRE | 1047-1100 | |
| 9 | 267-70-11351 | BUSHING | 1157- | |
| 267-70-11350 | BUSHING | 1047-1156 | ||
| 10 | 267-70-11343 | SPACER | 1157- | |
| 267-70-11342 | SPACER | 1101-1156 | ||
| 267-70-11341 | SPACER | 1047-1100 | ||
| 11 | 07007-02090 | PACKING | 1047- | |
| 12 | 267-70-15102 | WHEEL BRAKE ASS'Y | 1157- | |
| 267-70-15101 | WHEEL BRAKE ASS'Y | 1101-1156 | ||
| 267-70-15100 | WHEEL BRAKE ASS'Y | 1047-1100 | ||
| 13 | 267-70-11313 | RETAINER | 1157- | |
| 267-70-11312 | RETAINER | 1101-1156 | ||
| 267-70-11311 | RETAINER | 1047-1100 | ||
| 14 | 01040-31225 | BOLT | 1047- | |
| 15 | 267-70-15451 | WASHER | 1157- | |
| 267-70-15450 | WASHER | 1101-1156 | ||
| 01602-01236 | WASHER | 1047-1100 | ||
| 16 | 265-06-07000 | NUT | 1047- | |
| 17 | 267-70-11320 | WASHER | 1047- | |
| 18 | 265-07-07000 | WASHER | 1047- | |
| 19 | 07020-00000 | FITTING | 1047- | |
| 20 | 267-70-11610 | BUSHING | 1157- | |
| 267-70-11360 | BUSHING | 1047-1156 | ||
| 21 | 267-70-11372 | SPACER | 1157- | |
| 267-70-11371 | SPACER | 1097-1156 | ||
| 267-70-11370 | SPACER | 1047-1096 | ||
| 22 | 267-70-15430 | PACKING | 1097- | |
| 07007-09080 | PACKING | 1047-1096 | ||
| 23 | 267-70-11361 | SPACER | 1157- |
