| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 419-62-33912 | HOSE | B10001- | |
| 2 | 08210-00611 | SPIRAL TUBE | B10001- | |
| 3 | 11Y-62-12530 | UNION | B10001- | |
| 4 | 416-62-11480 | O-RING | B10001- | |
| 5 | 02896-11008 | O-RING | B10001- | |
| 6 | 04434-52712 | CLIP | B10001- | |
| 7 | 07095-20420 | CUSHION | B10001- | |
| 8 | 01010-81020 | BOLT | B10001- | |
| 9 | 01643-31032 | WASHER | B10001- | |
| 10 | 02764-002A5 | HOSE | B10001- | |
| 11 | 11Y-62-12120 | UNION | B10001- | |
| 12 | 416-62-11480 | O-RING | B10001- | |
| 13 | 02896-11008 | O-RING | B10001- | |
| 14 | 02783-10210 | ELBOW | B10001- | |
| 15 | 02896-11008 | O-RING | B10001- | |
| 16 | 07002-11423 | O-RING | B10001- | |
| 17 | 419-62-33674 | HOSE | B10001- | |
| 18 | 08210-01804 | SPIRAL TUBE | B10001- | |
| 19 | 08210-01803 | SPIRAL TUBE | B10001- | |
| 20 | 04434-52512 | CLIP | B10001- | |
| 21 | 01010-81020 | BOLT | B10001- | |
| 22 | 01643-31032 | WASHER | B10001- | |
| 23 | 418-62-32172 | NIPPLE | B10001- | |
| 24 | 418-62-11630 | O-RING | B10001- | |
| 25 | 419-62-31153 | ELBOW | B10001- | |
| 26 | 11Y-62-11980 | O-RING | B10001- | |
| 27 | 419-62-33653 | HOSE | B10001- | |
| 28 | 418-62-31430 | NIPPLE | B10001- | |
| 29 | 418-62-11620 | O-RING | B10001- | |
| 30 | 02896-11015 | O-RING | B10001- | |
| 31 | 07094-10518 | CLAMP | B10001- | |
| 32 | 07095-00523 | CUSHION | B10001- | |
| 33 | 01010-81270 | BOLT | B10001- | |
| 34 | 01643-31232 | WASHER | B10001- | |
| 35 | 419-64-35142 | BRACKET | B10001- | |
| 36 | 01010-81025 | BOLT | B10001- | |
| 37 | 01643-31032 | WASHER | B10001- |
