| Item | Part No. | Part Name | Qty | Serial No. |
| 13F-70-00011 | FRAME ASS'Y,L.H. | 81135- | ||
| 13F-70-00010 | FRAME ASS'Y,L.H. | 80001-81134 | ||
| 13F-70-00021 | FRAME ASS'Y,R.H. | 81135- | ||
| 13F-70-00020 | FRAME ASS'Y,R.H. | 80001-81134 | ||
| 1 | \6\ | FRAME,L.H. | 81135- | |
| 1 | \6\ | FRAME,L.H. | 80001-81134 | |
| 1 | \6\ | FRAME,R.H. | 81135- | |
| 1 | \6\ | FRAME,R.H. | 80001-81134 | |
| 2 | 13F-70-21191 | BRACKET (WELDED) | 80001- | |
| 3 | 13F-70-21191 | BRACKET,L.H. (WELDED) | 80001- | |
| 3 | 13F-70-31260 | BRACKET,R.H. (WELDED) | 80001- | |
| 4 | 13F-70-31240 | JOINT (WELDED) | 81135- | |
| 4 | 13F-Z27-2220 | JOINT (WELDED) | 80001-81134 | |
| 5 | 13F-Z27-2260 | BUSHING | 80001- | |
| 6 | 13F-Z27-2250 | BUSHING | 80001- | |
| 130-70-00072 | PIVOT ASS'Y,L.H. | 80001- | ||
| 13F-70-00130 | PIVOT ASS'Y,R.H. | 80001- | ||
| 7 | \6\ | PIVOT,L.H. | 80001- | |
| 7 | \6\ | BEARING,R.H. | 80001- | |
| 8 | 130-70-13231 | CAP,L.H. | 80001- | |
| 8 | 13F-70-21171 | CAP,R.H. | 80001- | |
| 9 | 01011-82440 | BOLT,L.H. | 80001- | |
| 9 | 01010-82475 | BOLT,R.H. | 80001- | |
| 10 | 01643-32460 | WASHER | 80001- | |
| 11 | 130-70-13241 | NUT | 80001- | |
| 12 | 13F-Z29-2220 | TRUNNION,L.H. | 80001- | |
| 12 | 13F-70-21150 | TRUNNION,R.H. | 80001- | |
| 13 | 130-817-5830 | SHAFT,L.H. (WELDED) | 80001- | |
| 13 | 144-Z20-3150 | SHAFT,R.H. (WELDED) | 80001- | |
| 14 | 01010-52045 | BOLT | 80001- | |
| 15 | 01643-32060 | WASHER | 80001- | |
| 13F-Z27-0030 | BRACE ASS'Y,CENTER | 80001- | ||
| 16 | 13F-Z27-4110 | BRACE | 80001- | |
| 16 | 144-817-2171 | JOINT,(WELDED) NOT SHOWN | 80001- | |
| 16 | 13F-Z27-4130 | RETAINER NOT SHOWN | 80001- | |
| 17 | 13F-Z27-4150 | JOINT | 80001- | |
| 18 | 01011-52015 | BOLT | 80001- | |
| 19 | 01580-12016 | NUT | 80001- | |
| 20 | 01643-32060 | WASHER | 80001- | |
| 13F-Z27-0040 | BRACE ASS'Y,TILT | 80001- | ||
| 21 | 13F-Z27-4510 | BRACE | 80001- | |
| 21 | 130-817-5590 | ROD | 80001- | |
| 22 | 07020-00000 | FITTING | 80001- | |
| 23 | 13F-Z27-4550 | JOINT | 80001- | |
| 24 | 13F-Z27-0050 | SHIM ASS'Y | 80001- | |
| 24 | \6\ | SHIM, 0.5MM | 80001- | |
| 24 | \6\ | SHIM, 1.0MM | 80001- | |
| 25 | 01010-52060 | BOLT | 80001- | |
| 26 | 01643-32060 | WASHER | 80001- | |
| 27 | 13F-Z27-5610 | PIN | 80001- | |
| 28 | 01010-31265 | BOLT | 80001- | |
| 29 | 01598-01214 | NUT | 80001- |
