| Item | Part No. | Part Name | Qty | Serial No. |
| 22-580375-00 | TAG LINE SUPPORT A. | (.)- | ||
| 22-580374-00 | TAG LINE ASS'Y | (1001)-(.) | ||
| 22-580201-00 | TAG LINE ASS'Y,15MM | (.)- | ||
| \0\22-580200-00 | TAG LINE ASS'Y,15MM | (1001)-(.) | ||
| 1 | 22-500193-21 | TUBE,OUTER | (1001)- | |
| 2 | 00200-97550 | CAP | (1001)- | |
| 3 | 22-590110-01 | PLUG,OIL LEVEL | (1001)- | |
| 4 | 22-500194-21 | TUBE,INNER | (1001)- | |
| 5 | 22-450316-01 | SPRING,TAG LINE | (1001)- | |
| 22-580202-00 | BEARING ASS'Y | (1001)- | ||
| 6 | 22-450315-21 | BEARING,INNER TUBE | (1001)- | |
| 7 | 22-401184-01 | BUSHING | (1001)- | |
| 8 | 07012-00060 | SEAL (KIT) | (1001)- | |
| 9 | 22-401186-01 | WASHER | (1001)- | |
| 22-580377-00 | DRUM ASS'Y | (1001)- | ||
| 10 | 22-540149-21 | DRUM,TAG ROPE | (1001)- | |
| 11 | 22-401396-01 | PLATE¤ NAME | (1001)- | |
| 12 | 22-401187-01 | GASKET (KIT) | (1001)- | |
| 13 | 02010-21057 | BOLT | (1001)- | |
| 14 | 02205-11015 | NUT | (1001)- | |
| 15 | 01601-01640 | WASHER | (1001)- | |
| 16 | 21-526456-01 | WEDGE | (1001)- | |
| 17 | 22-500234-21 | BRACKET | (1001)- | |
| 18 | 02010-21064 | BOLT | (1001)- | |
| 19 | 02205-11015 | NUT | (1001)- | |
| 20 | 01601-01640 | WASHER | (1001)- | |
| 21 | 21-287058-09 | SHEAVE,TAG ROPE GUIDE | (1001)- | |
| (\2\21-287058-02) | SHEAVE,TAG ROPE GUIDE | ((1001)-(.)) | ||
| 22 | 22-401397-01 | PIN | (.)- | |
| 23 | 00570-43760 | FITTING | (.)- | |
| 24 | 02205-11015 | NUT | (.)- | |
| 25 | 01601-01640 | WASHER | (.)- | |
| 26 | 22-401183-01 | PIN | (.)- | |
| 27 | 04050-03022 | PIN | (1001)- | |
| 22-580204-00 | SUPPORT ASS'Y | (1001)- | ||
| (\2\22-580203-00) | SUPPORT ASS'Y | ((1001)-(.)) | ||
| 28 | 22-400540-01 | BRACKET | (1001)- | |
| 29 | 02011-01014 | BOLT | (1001)- | |
| 30 | 02205-01015 | NUT | (1001)- | |
| 31 | 01601-01640 | WASHER | (1001)- | |
| 32 | 01640-01626 | WASHER | (1001)- | |
| 33 | 22-401098-01 | U-BOLT | (1001)- | |
| (\2\22-400542-01) | U-BOLT | ((1001)-(.)) | ||
| 34 | 01601-01640 | WASHER | (1001)- | |
| 35 | 02205-01015 | NUT | (1001)- | |
| 36 | 22-400543-01 | SUPPORT | (1001)- |
