| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 424-16-11310 | TUBE | 10001- | |
| 2 | 07042-20108 | PLUG | 10001- | |
| 3 | 07000-33028 | O-RING | 10001- | |
| 4 | 01010-51060 | BOLT | 10001- | |
| 5 | 01643-51032 | WASHER | 10001- | |
| 6 | 07102-20609 | HOSE, 900MM | 10001- | |
| 7 | 424-16-11460 | TUBE | 10001- | |
| 8 | 07000-33025 | O-RING | 10001- | |
| 9 | 01010-51050 | BOLT | 10552- | |
| 9 | \0\01010-51055 | BOLT | 10001-10551 | |
| 10 | 01643-51032 | WASHER | 10001- | |
| 11 | 424-16-11450 | TUBE | 10001- | |
| 12 | 07000-33025 | O-RING | 10001- | |
| 13 | 01010-51030 | BOLT | 10001- | |
| 14 | 01643-51032 | WASHER | 10001- | |
| 15 | 07102-20609 | HOSE, 900MM | 10001- | |
| 16 | 424-16-11370 | TUBE | 10001- | |
| 17 | 07000-33028 | O-RING | 10001- | |
| 18 | 01010-51030 | BOLT | 10001- | |
| 19 | 01643-51032 | WASHER | 10001- | |
| 20 | 424-09-12570 | CLIP | 10001- | |
| 21 | 01010-51025 | BOLT | 10001- | |
| 22 | 01643-31032 | WASHER | 10001- | |
| 23 | 08035-03014 | CLIP | 10001- | |
| 24 | 01010-51225 | BOLT | 10001- | |
| 25 | 01643-31232 | WASHER | 10001- | |
| 26 | 156-61-11590 | CLAMP | 10001- | |
| 27 | 01010-51025 | BOLT | 10001- | |
| 28 | 01602-21030 | WASHER,SPRING | 10001- | |
| 29 | 01580-11008 | NUT | 10001- |
