Item | Part No. | Part Name | Qty | Serial No. |
1 | 13E-43-25110 | LEVER | 65001- | |
2 | 09361-01460 | BUSHING | 65001- | |
3 | 09304-01240 | KNOB | 65001- | |
4 | 13E-43-25140 | BRACKET | 65001- | |
5 | 07020-00000 | FITTING | 65001- | |
6 | 01010-31225 | BOLT | 65001- | |
7 | 01602-01236 | WASHER | 65001- | |
8 | 13E-43-25150 | SHAFT | 65001- | |
9 | 124-43-25220 | SHAFT | 65001- | |
10 | 06120-01612 | BEARING | 65001- | |
11 | 06122-01603 | SEAL | 65001- | |
12 | 07020-00900 | FITTING | 65001- | |
13 | 04050-14045 | PIN | 65001- | |
14 | 06120-02216 | BEARING | 65001- | |
15 | 06122-02204 | SEAL | 65001- | |
16 | 01640-02232 | WASHER | 65001- | |
17 | 13E-43-25160 | LEVER | 65001- | |
18 | 04010-00519 | KEY | 65001- | |
19 | 01010-30830 | BOLT | 65001- | |
20 | 01602-00825 | WASHER | 65001- | |
21 | 13E-43-25170 | ROD | 65001- | |
22 | 07020-00001 | FITTING | 65001- | |
23 | 04248-31014 | ROD | 65001- | |
24 | 04252-11061 | END,ROD¤ L.H. THREAD | 65001- | |
25 | 04250-61056 | END,ROD¤ L.H. THREAD | 65001- | |
26 | 04252-01061 | END | 65001- | |
27 | 04250-41056 | END | 65001- | |
28 | 01583-01006 | NUT | 65001- | |
29 | 01508-11006 | NUT¤ L.H. THREAD,L.H. THREAD | 65001- | |
30 | 01593-01008 | NUT | 65001- | |
31 | 04050-12018 | PIN | 65001- | |
32 | 13E-43-25130 | LEVER | 65001- | |
33 | 09305-00800 | KNOB | 65001- | |
34 | 13E-43-25120 | STOPPER | 65001- | |
35 | 04025-00316 | PIN | 65001- | |
36 | 113-43-11280 | SPRING | 65001- |
