| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-49-11362 | FLANGE | 3689- | |
| 2 | 07000-13030 | O-RING | 3689- | |
| 3 | 01010-80860 | BOLT | 3689- | |
| 4 | 01643-30823 | WASHER | 3689- | |
| 5 | 07235-50628 | ELBOW | 3689- | |
| 6 | 07002-02434 | O-RING | 3689- | |
| 7 | 07042-30108 | PLUG | 3689- | |
| 8 | 07108-20616 | HOSE | 3689- | |
| 9 | 01010-81045 | BOLT | 3689- | |
| 10 | 01643-31032 | WASHER | 3689- | |
| 11 | 07042-30108 | PLUG | 3689- | |
| 12 | 07108-20622 | HOSE | 3689- | |
| 13 | 154-49-52110 | BRACKET | 3689- | |
| 14 | 176-61-41420 | CLIP | 3689- | |
| 15 | 01010-81040 | BOLT | 3689- | |
| 16 | 01643-31032 | WASHER | 3689- | |
| 17 | 154-49-51970 | CLAMP | 3689- | |
| 18 | 01010-81230 | BOLT | 3689- | |
| 19 | 01643-31232 | WASHER | 3689- | |
| 20 | 01010-81055 | BOLT | 3689- | |
| 21 | 01643-31032 | WASHER | 3689- | |
| 22 | 01010-81225 | BOLT | 3689- | |
| 23 | 01643-31232 | WASHER | 3689- | |
| 24 | 154-49-51970 | CLAMP | 3689- | |
| 25 | 01010-81025 | BOLT | 3689- | |
| 26 | 01643-31032 | WASHER | 3689- | |
| 27 | 154-49-51450 | BRACKET | 3689- | |
| 28 | 01010-81030 | BOLT | 3689- | |
| 29 | 01010-81045 | BOLT | 3689- | |
| 30 | 01643-31032 | WASHER | 3689- | |
| 31 | 07102-21009 | HOSE | 3689- | |
| 32 | 209-62-14550 | ELBOW | 3689- | |
| 33 | 07002-02434 | O-RING | 3689- | |
| 34 | 07042-30108 | PLUG | 3689- | |
| 35 | 154-49-51270 | ELBOW | 3689- | |
| 36 | 07002-02434 | O-RING | 3689- |
