| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 567-16-11313 | TUBE | 1384- | |
| 1 | 567-16-11312 | TUBE | 1101-1383 | |
| 1 | 567-16-11311 | TUBE | 1002-1100 | |
| 2 | 07000-23048 | O-RING | 1101- | |
| 2 | 07000-23045 | O-RING | 1002-1100 | |
| 3 | 01010-31235 | BOLT | 1101- | |
| 3 | 01010-31250 | BOLT | 1002-1100 | |
| 4 | 01010-31235 | BOLT | 1101- | |
| 4 | 01010-31270 | BOLT | 1002-1100 | |
| 5 | 01602-01236 | WASHER | 1002- | |
| 6 | 07260-24113 | HOSE | 1015- | |
| 6 | 07260-24111 | HOSE | 1002-1014 | |
| 7 | 07281-00609 | CLAMP | 1101- | |
| 7 | 07281-00709 | CLAMP | 1002-1100 | |
| 8 | 567-16-11323 | TUBE | 1384- | |
| 8 | 567-16-11322 | TUBE | 1101-1383 | |
| 8 | 567-16-11321 | TUBE | 1002-1100 | |
| 9 | 07000-23045 | O-RING | 1002- | |
| 10 | 01010-31260 | BOLT | 1002- | |
| 11 | 01010-31280 | BOLT | 1002- | |
| 12 | (07436-66101) | PUMP ASS'Y | 1002- | |
| 13 | 07000-22075 | O-RING | 1002- | |
| 14 | 01010-31250 | BOLT | 1002- | |
| 15 | 567-16-11341 | TUBE | 1002- | |
| 16 | 07042-20108 | PLUG | 1002- | |
| 17 | 07000-23035 | O-RING | 1002- | |
| 18 | 01010-31060 | BOLT | 1002- | |
| 19 | 01010-31065 | BOLT | 1002- | |
| 20 | 01602-01030 | WASHER | 1002- | |
| 21 | 07118-01008 | HOSE | 1002- | |
| 22 | 07000-23032 | O-RING | 1002- | |
| 23 | 07371-21044 | FLANGE | 1215- | |
| 23 | \0\07371-01044 | FLANGE | 1002-1214 | |
| 24 | 07372-21030 | BOLT | 1002- | |
| 25 | 565-62-11203 | OIL FILTER ASS'Y | 1215- | |
| 25 | \0\565-62-11202 | OIL FILTER ASS'Y | 1113-1214 | |
| 25 | 565-62-11201 | OIL FILTER ASS'Y | 1053-1112 | |
| 25 | \0\565-62-11200 | OIL FILTER ASS'Y | 1002-1052 | |
| 26 | 01010-31230 | BOLT | 1002- | |
| 27 | 01602-01236 | WASHER | 1002- | |
| 28 | 567-16-11362 | TUBE | 1384- | |
| 28 | 567-16-11361 | TUBE | 1002-1383 | |
| 29 | 07000-23028 | O-RING | 1002- | |
| 30 | 07372-21035 | BOLT | 1002- | |
| 31 | 01602-01030 | WASHER | 1002- | |
| 32 | 567-16-11211 | TUBE | 1053- | |
| 32 | 573-16-11230 | TUBE | 1002-1052 | |
| 33 | 07000-23035 | O-RING | 1053- | |
| 33 | 07000-23032 | O-RING | 1002-1052 | |
| 34 | 01010-31065 | BOLT | 1053- | |
| 34 | 01010-31060 | BOLT | 1002-1052 | |
| 35 | 01602-01030 | WASHER | 1002- | |
| 36 | 07102-21009 | HOSE | 1053- | |
| 36 | 07108-20609 | HOSE | 1002-1052 | |
| 37 | 567-16-11231 | TUBE | 1053- | |
| 37 | 567-16-11230 | TUBE | 1002-1052 | |
| 38 | 07206-12227 | BOLT | 1002- | |
| 39 | 07005-02716 | GASKET | 1002- | |
| 40 | 07102-20405 | HOSE | 1101- | |
| 41 | 07232-10422 | ELBOW | 1101- | |
| 42 | 07239-12009 | NUT | 1101- | |
| 43 | 07002-22034 | O-RING | 1101- | |
| 44 | 567-16-11223 | BRACKET | 1101- | |
| 44 | 567-16-11222 | BRACKET | 1053-1100 | |
| 44 | 573-16-11220 | BRACKET | 1002-1052 | |
| 45 | 07283-13442 | CLIP | 1053- | |
| 45 | 07283-12738 | CLIP | 1002-1052 | |
| 46 | 01643-21032 | WASHER | 1002- | |
| 47 | 01599-01011 | NUT | 1002- | |
| 48 | 281-01-13180 | CLIP | 1053- | |
| 48 | 08036-03014 | CLIP | 1002-1052 |
