| Item | Part No. | Part Name | Qty | Serial No. |
| (561-13-00110) | TORQUE CONVERTER A. | 2001- | ||
| (\2\561-13-00010) | TORQUE CONVERTER A. | (2001-2298) | ||
| THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2301 TO 2311. | ||||
| 1 | 561-13-41120 | PUMP | 2001- | |
| 2 | 07040-11007 | PLUG | 2001- | |
| 3 | 711-28-41140 | RETAINER | 2001- | |
| 4 | 711-28-41190 | GUIDE | 2001- | |
| 5 | 01010-61050 | BOLT | 2001- | |
| 6 | 01643-31032 | WASHER | 2001- | |
| 7 | 01010-61040 | BOLT | 2001- | |
| 8 | 01643-31032 | WASHER | 2001- | |
| 9 | 561-13-42110 | STATOR | 2001- | |
| 10 | 711-28-42120 | RACE | 2001- | |
| 11 | 01010-61025 | BOLT | 2001- | |
| 12 | 01643-31032 | WASHER | 2001- | |
| 13 | 711-28-32160 | WHEEL,FREE | 2001- | |
| 14 | 711-28-22141 | BUSHING | 2001- | |
| 15 | 568-13-12140 | BUSHING | 2001- | |
| 16 | 04260-00635 | BALL | 2001- | |
| 17 | 04077-00140 | RING,SNAP | 2001- | |
| 561-13-00040 | SHAFT ASS'Y | 2001- | ||
| 18 | \6\ | SHAFT | 2001- | |
| 19 | 711-31-13140 | PLUG,(D=1.0MM) | 2001- | |
| 20 | 07043-70211 | PLUG | 2001- | |
| 21 | 07018-31907 | RING,SEAL | 2001- | |
| 22 | 711-28-41180 | BEARING | 2001- | |
| 23 | 711-28-42680 | NUT | 2001- | |
| 24 | 01010-61230 | BOLT | 2001- | |
| 25 | 01643-31232 | WASHER | 2001- |
