| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 198-30-17151 | COVER,L.H. | 1011-1012 | |
| 1 | 198-30-17152 | COVER,L.H. | 1007-1010 | |
| 1 | 198-30-17151 | COVER,L.H. | 1004-1006 | |
| 1 | 198-30-17150 | COVER,L.H. | 1002-1003 | |
| 2 | 198-30-17161 | COVER,R.H. | 1011-1012 | |
| 2 | 198-30-17162 | COVER,R.H. | 1007-1010 | |
| 2 | 198-30-17161 | COVER,R.H. | 1004-1006 | |
| 2 | 198-30-17160 | COVER,R.H. | 1002-1003 | |
| 3 | 01016-31250 | BOLT | 1004-@ | |
| 3 | 01016-31245 | BOLT | 1002-1003 | |
| 4 | 01641-01223 | WASHER | 1002-@ | |
| 5 | 01580-11210 | NUT | 1002-@ | |
| 6 | 01010-31850 | BOLT | 1002-1012 | |
| 7 | 01602-01854 | WASHER | 1002-@ | |
| 8 | 01643-01845 | WASHER | 1002-@ | |
| 9 | 198-30-17110 | SUPPORT,L.H. | 1002-1012 | |
| 10 | 198-30-17120 | SUPPORT,R.H. | 1002-1012 | |
| 11 | 01010-32785 | BOLT | 1002-1012 | |
| 12 | 01602-02783 | WASHER | 1002-1012 | |
| 13 | 141-70-13310 | WASHER | 1002-1012 | |
| 14 | 198-30-17190 | STOPPER | 1002-1012 | |
| 15 | 01010-32060 | BOLT | 1002-@ | |
| 16 | 01602-02060 | WASHER | 1002-@ | |
| 17 | 198-30-17170 | COVER | 1011-1012 | |
| 17 | 198-30-17171 | COVER | 1007-1010 | |
| 17 | 198-30-17170 | COVER | 1002-1006 | |
| 18 | 01010-31850 | BOLT | 1002-1012 | |
| 19 | 01602-01854 | WASHER | 1002-1012 | |
| 20 | 01643-01845 | WASHER | 1002-1012 | |
| 21 | 198-30-17130 | SUPPORT,L.H. | 1002-1012 | |
| 22 | 198-30-17140 | SUPPORT,R.H. | 1002-1012 | |
| 23 | 198-30-17180 | COVER | 1011-1012 | |
| 23 | 198-30-17181 | COVER | 1007-1010 | |
| 23 | 198-30-17180 | COVER | 1002-1006 | |
| 24 | 01010-31850 | BOLT | 1002-1012 | |
| 25 | 01602-01854 | WASHER | 1002-1012 | |
| 26 | 01643-31845 | WASHER | 1002-1012 | |
| 27 | 198-30-11470 | PLATE | 1004-1012 | |
| 28 | 01010-31240 | BOLT | 1004-1012 | |
| 29 | 01602-01236 | WASHER | 1004-1012 |
