| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 01010-81645 | Bolt | 30001-@ | |
| 2 | 13Y-30-16190 | Washer | 30001-@ | |
| 3 | 13Y-30-16551 | Guard | 30001-@ | |
| 3 | 13Y-30-16550 | Guard | 30001-30117 | |
| 4 | 13Y-30-16561 | Guard | 30001-@ | |
| 4 | 13Y-30-16560 | Guard | 30001-30117 | |
| 5 | 13Y-30-16180 | Pipe | 30001-@ | |
| 6 | 09205-18305 | Bolt | 30001-@ | |
| 7 | 01643-31845 | Washer | 30001-@ | |
| 8 | 01580-11815 | Nut | 30001-@ | |
| 9 | 13Y-30-11171 | Bracket | 30001-@ | |
| 10 | 13Y-30-11181 | Bracket | 30001-@ | |
| 11 | 01010-81245 | Bolt | 30001-@ | |
| 12 | 01643-31232 | Washer | 30001-@ | |
| 13 | 134-30-61450 | Plate | 30001-@ | |
| 14 | 01010-81230 | Bolt | 30001-@ | |
| 15 | 01643-31232 | Washer | 30001-@ | |
| 16 | 13Y-30-16514 | Guard | 30118-@ | |
| 16 | 13Y-30-16513 | Guard | 30001-30117 | |
| 17 | 13Y-30-16190 | Washer | 30001-@ | |
| 18 | 13Y-30-16190 | Washer | 30001-31895 | |
| 19 | 01010-81645 | Bolt | 30001-@ | |
| 20 | 01010-81645 | Bolt | 30001-31895 | |
| 21 | 01010-81675 | Bolt | 30001-@ | |
| 22 | 13Y-30-16524 | Guard | 30118-@ | |
| 22 | 13Y-30-16523 | Guard | 30001-30117 | |
| 23 | 13Y-30-16190 | Washer | 30001-@ | |
| 24 | 13Y-30-16190 | Washer | 30001-31895 | |
| 25 | 01010-81645 | Bolt | 30001-@ | |
| 26 | 01010-81675 | Bolt | 30001-@ | |
| 27 | 01010-81645 | Bolt | 30001-31895 | |
| 28 | 13Y-30-14133 | Guard | 30001-@ | |
| 29 | 13Y-30-14143 | Guard | 30001-@ | |
| 30 | 01010-81645 | Bolt | 30001-@ | |
| 31 | 01643-31645 | Washer | 30001-@ | |
| 32 | 07049-01215 | Plug | 30001-@ |
