| Item | Part No. | Part Name | Qty | Serial No. |
| SWAMP 910MM | ||||
| 154-820-0214 | TRACK SHOE ASS'Y | ...- | ||
| \0\154-820-0213 | TRACK SHOE ASS'Y | ..-... | ||
| \0\154-820-0212 | TRACK SHOE ASS'Y | 2093-.. | ||
| \0\154-820-0211 | TRACK SHOE ASS'Y | .-2092 | ||
| \0\154-820-0210 | TRACK SHOE ASS'Y | 2001-. | ||
| 1 | 154-820-1120 | SHOE,TRACK | 1007- | |
| 2 | 154-820-1211 | BOLT (KIT) | ...- | |
| 2 | 154-820-1210 | BOLT,SHOE (KIT) | 1007-... | |
| 3 | 154-32-31220 | NUT, SHOE (KIT) | ...- | |
| 3 | 01803-02026 | NUT, SHOE (KIT) | 1001-... | |
| 154-32-00264 | TRACK LINK ASS'Y | ...- | ||
| \0\154-32-00263 | TRACK LINK ASS'Y | ..-... | ||
| \0\154-32-00262 | TRACK LINK ASS'Y | 2093-.. | ||
| \0\154-32-00261 | TRACK LINK ASS'Y | .-2092 | ||
| \0\154-32-00260 | TRACK LINK ASS'Y | 2001-. | ||
| 4 | 154-32-11127 | LINK,TRACK, L.H. | 2093- | |
| 4 | \0\154-32-11126 | LINK,TRACK, L.H. | .-2092 | |
| 4 | \0\154-32-11125 | LINK,TRACK, L.H. | 2001-. | |
| 5 | 154-32-11137 | LINK,TRACK, R.H. | 2093- | |
| 5 | \0\154-32-11136 | LINK,TRACK, R.H. | .-2092 | |
| 5 | \0\154-32-11135 | LINK,TRACK, R.H. | 2001-. | |
| 6 | 154-32-31141 | BUSHING,REGULAR | ...- | |
| 6 | \0\154-32-31140 | BUSHING, REGULAR | 2001-... | |
| 7 | 154-32-11283 | SEAL,DUST, REGULAR, W-TYPE | 2001- | |
| 8 | 154-820-1153 | PIN | ..- | |
| 8 | \0\154-820-1151 | PIN,REGULAR | 2001-.. | |
| 9 | 154-32-31171 | BUSHING,MASTER | ...- | |
| 9 | \0\154-32-31170 | BUSHING, MASTER | 2001-... | |
| 10 | 154-32-11260 | SEAL,DUST, MASTER, E-TYPE | 1001- | |
| 11 | 154-820-1192 | PIN | ..- | |
| 11 | \0\154-820-1191 | PIN,MASTER | 2001-.. | |
| SERVICE KIT | ||||
| 1 | 154-820-0501 | SHOE BOLT AND NUT K. | ...- | |
| 1 | \0\154-820-0500 | SHOE BOLT AND NUT K. | 1007-... | |
| 2 | 154-820-1211 | BOLT | ...- | |
| 2 | 154-820-1210 | BOLT,SHOE | 1007-... | |
| 3 | 154-32-31220 | NUT, SHOE | ...- | |
| 3 | 01803-02026 | NUT, SHOE | 1001-... | |
| SINGLE 910MM | ||||
| 1 | 154-820-0222 | TRACK SHOE ASS'Y | ...- | |
| 1 | \0\154-820-0221 | TRACK SHOE ASS'Y | ..-... | |
| 1 | \0\154-820-0220 | TRACK SHOE ASS'Y | 2001-.. | |
| 1 | 154-820-1310 | SHOE,TRACK | 1007- | |
| 2 | 154-32-31210 | BOLT, SHOE (KIT) | ...- | |
| 2 | 154-820-1240 | BOLT (KIT) | 2001-... | |
| 3 | 154-32-31220 | NUT, SHOE (KIT) | ...- | |
| 3 | 01803-02026 | NUT, SHOE (KIT) | 2001-... | |
| 4 | 154-32-00264 | TRACK LINK ASS'Y | ...- | |
| 4 | \0\154-32-00263 | TRACK LINK ASS'Y | ..-... | |
| 4 | \0\154-32-00262 | TRACK LINK ASS'Y | 2001-.. | |
| SERVICE KIT,(FOR SINGLE) | ||||
| 1 | 154-820-0511 | SHOE BOLT AND NUT K. | ...- | |
| 1 | \0\154-820-0510 | SHOE BOLT AND NUT K. | 2001-... | |
| 2 | 154-32-31210 | BOLT, SHOE | ...- | |
| 2 | 154-820-1240 | BOLT | 2001-... | |
| 3 | 154-32-31220 | NUT, SHOE | ...- | |
| 3 | 01803-02026 | NUT, SHOE | 2001-... | |
| OVERSIZE PARTS | ||||
| 0.10MM OVERSIZE | ||||
| 6 | 154-98-09411 | BUSHING, REGULAR | ...- | |
| 6 | 154-98-09410 | BUSHING, REGULAR | 2001-... | |
| 8 | 154-98-09212 | PIN, REGULAR | ..- | |
| 8 | \0\154-98-09211 | PIN, REGULAR | 2001-.. | |
| 9 | 154-98-09441 | BUSHING, MASTER | ...- | |
| 9 | \0\154-98-09440 | BUSHING, MASTER | 2001-... | |
| 11 | 154-98-09242 | PIN, MASTER | ..- | |
| 11 | \0\154-98-09241 | PIN, MASTER | 2001-.. | |
| 0.18MM OVERSIZE | ||||
| 6 | 154-98-09431 | BUSHING, REGULAR | ...- | |
| 6 | 154-98-09430 | BUSHING, REGULAR | 2001-... | |
| 8 | 154-98-09232 | PIN, REGULAR | ..- | |
| 8 | \0\154-98-09231 | PIN, REGULAR | 2001-.. | |
| 9 | 154-98-09461 | BUSHING, MASTER | ...- | |
| 9 | 154-98-09460 | BUSHING, MASTER | 2001-... | |
| 11 | 154-98-09262 | PIN, MASTER | ..- | |
| 11 | \0\154-98-09261 | PIN, MASTER | 2001-.. |
