| Item | Part No. | Part Name | Qty | Serial No. |
| (714-20-10010) | TRANSFER ASS'Y | 23001- | ||
| THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 AND F2320-52A0. | ||||
| 1 | 06120-02016 | BEARING | 23001- | |
| 2 | 714-09-16190 | SEAL | 23001- | |
| 3 | 714-20-17210 | LEVER | 23001- | |
| 4 | 714-09-16181 | LEVER | 23001- | |
| 5 | 714-09-16271 | SPACER | 23001- | |
| 6 | 01252-30816 | BOLT | 23001- | |
| 7 | 714-09-16282 | WASHER | 23001- | |
| 8 | 04260-01587 | BALL | 23001- | |
| 9 | 714-09-16311 | PISTON ASS'Y | 23001- | |
| 10 | 714-09-16240 | E-RING | 23001- | |
| 11 | 04022-20080 | PIN | 23001- | |
| 12 | 714-09-16130 | PLATE | 23001- | |
| 13 | 714-09-16140 | DISC | 23001- | |
| 14 | 714-09-16150 | SPRING | 23001- | |
| 15 | 07030-00252 | BREATHER | 23001- | |
| 16 | 07323-20200 | ELBOW | 23001- | |
| 17 | 07044-12412 | PLUG | 23001- | |
| 18 | 07002-02434 | O-RING | 23001- | |
| 19 | 09608-05080 | PLATE, NAME,(LIMITED SUPPLY) | 23001- | |
| 20 | 04418-13060 | SCREW | 23001- |
