| Item | Part No. | Part Name | Qty | Serial No. |
| (230-14-00230) | TRANSMISSION ASS'Y | 1533- | ||
| (230-14-00229) | TRANSMISSION ASS'Y | 1486-1532 | ||
| (230-14-00228) | TRANSMISSION ASS'Y | 1485-1485 | ||
| (230-14-00229) | TRANSMISSION ASS'Y | 1483-1484 | ||
| (230-14-00228) | TRANSMISSION ASS'Y | 1263-1482 | ||
| (230-14-00227) | TRANSMISSION ASS'Y | 1252-1262 | ||
| (230-14-00226) | TRANSMISSION ASS'Y | 1072-1251 | ||
| (230-14-00225) | TRANSMISSION ASS'Y | 801-1071 | ||
| (230-14-00224) | TRANSMISSION ASS'Y | 310-800 | ||
| (230-14-00223) | TRANSMISSION ASS'Y | 255-309 | ||
| (230-14-00222) | TRANSMISSION ASS'Y | 235-254 | ||
| (230-14-00221) | TRANSMISSION ASS'Y | 215-234 | ||
| (230-14-00220) | TRANSMISSION ASS'Y | 185-214 | ||
| 1 | 230-14-11281 | RETAINER | 310- | |
| 230-14-11280 | RETAINER | 185-309 | ||
| 2 | 07010-01070 | SEAL | 185- | |
| 3 | 230-14-11290 | GASKET (KIT) | 185- | |
| 4 | 01010-31225 | BOLT | 1252- | |
| 01000-31225 | BOLT | 310-1251 | ||
| 01004-31225 | BOLT | 185-309 | ||
| 5 | 230-14-11310 | WASHER | 310- | |
| 04059-01663 | WIRE | 185-309 | ||
| 6 | 230-14-11320 | RETAINER | 185- | |
| 7 | 230-14-11330 | GASKET (KIT) | 185- | |
| 8 | 230-14-11342 | RETAINER | 185- | |
| 9 | 230-14-11410 | SHIM¤ 0.2MM | 185-800 | |
| 10 | 230-14-11420 | GASKET (KIT) | 185- | |
| 11 | 01010-31045 | BOLT | 1252- | |
| 01000-31045 | BOLT | 185-1251 | ||
| 12 | 01010-31035 | BOLT | 1252- | |
| 01000-31035 | BOLT | 185-1251 | ||
| 13 | 01602-01030 | WASHER | 185- | |
| 14 | 07012-00050 | SEAL | 185- | |
| 15 | 230-14-11354 | GEAR | 801- | |
| 230-14-11353 | GEAR | 215-800 | ||
| 230-14-11352 | GEAR | 185-214 | ||
| 16 | 230-14-11380 | WASHER | 185- | |
| 17 | 230-14-11361 | BUSHING | 185- | |
| 18 | 230-14-11370 | GASKET (KIT) | 185- | |
| 19 | 01225-40616 | SCREW | .- | |
| 01214-50616 | SCREW | 185-. | ||
| 20 | 230-14-11390 | GASKET (KIT) | 185- | |
| 21 | 230-14-11432 | RETAINER | 801- | |
| 230-14-11431 | RETAINER | 185-800 | ||
| 22 | 230-14-11440 | SHIM¤ 0.2MM | 185-800 | |
| 22A | 07000-03045 | O-RING | 801- | |
| 23 | 01010-31040 | BOLT | 1252- | |
| 01000-31035 | BOLT | 801-1251 | ||
| 01000-31025 | BOLT | 185-800 | ||
| 24 | 01602-01030 | WASHER | 185- | |
| 25 | 230-14-11452 | RETAINER | 1072- | |
| 230-14-11451 | RETAINER | 185-1071 | ||
| 26 | 230-14-11710 | GASKET (KIT) | 1072- | |
| 230-14-11460 | GASKET (KIT) | 185-1071 | ||
| 27 | 230-14-11475 | RETAINER | 1533- | |
| 230-14-11474 | RETAINER | 1072-1532 | ||
| 230-14-11473 | RETAINER | 185-1071 | ||
| 28 | 04065-06220 | RING | 185- | |
| 29 | 01124-31045 | STUD | 1252- | |
| 01100-31045 | STUD | 1072-1251 | ||
| 01000-31035 | BOLT | 185-1071 | ||
| 30 | 01602-01030 | WASHER | 185- | |
| 30A | 01580-01008 | NUT | 1252- | |
| 01500-31008 | NUT | 1072-1251 | ||
| 31 | 07011-00035 | SEAL | 185- | |
| 32 | 230-14-11480 | FLANGE | 185- | |
| 33 | 230-14-11490 | GASKET (KIT) | 185- | |
| 34 | 01010-30822 | BOLT | 1252- | |
| 01000-30822 | BOLT | 185-1251 | ||
| 35 | 01602-00825 | WASHER | 185- | |
| 36 | 230-14-11590 | SEAL | 185- | |
| 37 | 230-14-11610 | RETAINER | 801- | |
| 38 | 230-14-11620 | GASKET (KIT) | 801- | |
| 39 | 07000-13098 | O-RING | 801- | |
| 40 | 230-14-11720 | COVER | 1263-1532 | |
| 41 | 232-43-31220 | GASKET | 1263-1532 | |
| 42 | 01010-31030 | BOLT | 1263-1532 | |
| 43 | 01602-01030 | WASHER | 1263-1532 | |
| 44 | 07012-00028 | SEAL | 1533- | |
| 07010-00025 | SEAL | 1263-1532 |
