| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 267-10-14400 | HOOD | 1047- | |
| 2 | 267-10-15120 | STOPPER | 1047- | |
| 3 | 01220-40516 | SCREW | 1137- | |
| 01220-20516 | SCREW | 1047-1136 | ||
| 4 | 265-04-85000 | NUT | 1137- | |
| 01500-00504 | NUT | 1047-1136 | ||
| 5 | 01642-00508 | WASHER | 1047- | |
| 6 | 01601-00513 | WASHER | 1047- | |
| 7 | 267-10-15130 | STAY | 1047- | |
| 8 | 267-10-15150 | PIN | 1047- | |
| 9 | 01642-00608 | WASHER | 1047- | |
| 10 | 04050-02012 | PIN | 1047- | |
| 11 | 267-10-15140 | PIN | 1047- | |
| 12 | 01642-01016 | WASHER | 1047- | |
| 13 | 04050-03020 | PIN | 1047- | |
| 14 | 267-10-14500 | HOOD | 1047- | |
| 15 | 267-10-15120 | STOPPER | 1047- | |
| 16 | 01220-40516 | SCREW | 1137- | |
| 01220-20516 | SCREW | 1047-1136 | ||
| 17 | 265-04-85000 | NUT | 1137- | |
| 01500-00504 | NUT | 1047-1136 | ||
| 18 | 01642-00508 | WASHER | 1047- | |
| 19 | 01601-00513 | WASHER | 1047- | |
| 20 | 267-10-15130 | STAY | 1047- | |
| 21 | 267-10-15150 | PIN | 1047- | |
| 22 | 01642-00608 | WASHER | 1047- | |
| 23 | 04050-02012 | PIN | 1047- | |
| 24 | 267-10-15140 | PIN | 1047- | |
| 25 | 01642-01016 | WASHER | 1047- | |
| 26 | 04050-03020 | PIN | 1047- |
