| Item | Part No. | Part Name | Qty | Serial No. |
| (428-15-00070) | TRANSMISSION ASS'Y | 10001- | ||
| 1 | 428-15-12111 | SHAFT | 10001- | |
| 2 | 07018-20353 | RING,SEAL | 10001- | |
| 3 | 07018-10904 | RING,SEAL | 10001- | |
| 4 | 712-74-Z2210 | GEAR | 10001- | |
| 5 | 428-15-12310 | CARRIER | 10001- | |
| 6 | 712-74-Z2410 | GEAR | 10001- | |
| 7 | 195-15-49430 | BEARING | 10001- | |
| 8 | 195-15-32570 | WASHER,THRUST | 10001- | |
| 9 | 428-15-12511 | SHAFT | 10001- | |
| 10 | 04025-00624 | PIN,SPRING | 10001- | |
| 11 | 428-15-12650 | GEAR,RING | 10001- | |
| 428-15-00150 | HOUSING ASS'Y | 10001- | ||
| 12 | \6\ | HOUSING | 10001- | |
| 13 | 145-14-11320 | PLUG | 10001- | |
| 14 | 287-15-19220 | RING,SEAL (K3) | 10001- | |
| 15 | 428-15-12730 | PISTON | 10001- | |
| 16 | 155-15-12811 | RING,SEAL (K3) | 10001- | |
| 17 | 428-15-12660 | GEAR,RING | 10001- | |
| 18 | 428-15-12710 | DISC | 10001- | |
| 19 | 428-15-12790 | PLATE | 10001- | |
| 20 | 175-15-42880 | SPRING | 10001- | |
| 21 | 428-15-11270 | PIN,(D=15, L=290) | 10001- | |
| 22 | 195-15-12850 | SPRING,(L=91) | 10001- | |
| 23 | 428-15-12821 | COLLAR | 10001- | |
| 24 | 04020-01024 | PIN,DOWEL | 10001- | |
| 25 | 195-15-49240 | RING,SEAL | 10001- | |
| 428-15-00220 | HOUSING ASS'Y | 10001- | ||
| 26 | \6\ | HOUSING | 10001- | |
| 27 | 562-15-11450 | PLUG | 10001- | |
| 28 | 428-15-19261 | RING,SEAL | 10001- | |
| 29 | 06000-06932 | BEARING | 10001- | |
| 30 | 04070-00160 | RING,SNAP | 10001- | |
| 31 | 04071-00220 | RING,SNAP | 10001- | |
| 32 | 428-15-11260 | BOLT | 10001- | |
| 33 | 428-15-11250 | BOLT | 10001- | |
| 34 | 145-14-11570 | WASHER | 10001- | |
| 35 | 06000-06932 | BEARING | 10001- | |
| 36 | 04064-07525 | RING,SNAP | 10001- | |
| 37 | 04071-00130 | RING,SNAP | 10001- | |
| 38 | 07018-10753 | RING,SEAL | 10001- | |
| 39 | 04020-01434 | PIN,DOWEL | 10001- |
