| Item | Part No. | Part Name | Qty | Serial No. |
| (195-13-11004) | TORQUE CONVERTER A.,(TCS44-3B) | K1337-. | ||
| (195-13-11003) | TORQUE CONVERTER A.,(TCS44-3A) | K1012-K1336 | ||
| THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.221(IDEX NO.1 TO 65) AND 222. | ||||
| 195-13-11112 | PUMP ASS'Y | K1012-K1336 | ||
| 1 | 195-13-11123 | PUMP | K1337-. | |
| 195-13-11122 | PUMP | K1012-K1336 | ||
| 2 | 01190-01008 | HELISERT | K1012-K1336 | |
| 3 | 01010-61035 | BOLT | K1012-. | |
| 4 | 01602-21030 | WASHER | K1012-. | |
| 5 | 01643-31032 | WASHER | K1435-. | |
| 01642-21016 | WASHER | K1012-K1434 | ||
| 6 | 195-13-11142 | GEAR | K1337-. | |
| 195-13-11141 | GEAR | K1012-K1336 | ||
| 7 | 06032-01021 | BEARING | K1337-. | |
| 06032-00221 | BEARING | K1012-K1336 | ||
| 8 | 195-13-11160 | PLATE | K1337-. | |
| 04067-00190 | RING | K1012-K1336 | ||
| 9 | 195-13-11152 | PLATE (KIT) | K1337-. | |
| 195-13-11151 | PLATE (KIT) | K1012-K1336 | ||
| 10 | 01010-51035 | BOLT | K1337- | |
| 01010-51020 | BOLT | K1012-K1336 | ||
| 195-13-00010 | CASE ASS'Y | K1012-. | ||
| 11 | 195-13-91211 | CASE | K1640- | |
| \6\ | CASE | K1337-K1639 | ||
| \6\ | CASE | K1012-K1336 | ||
| 12 | 175-13-21220 | GEAR | K1640- | |
| 195-13-11220 | GEAR | K1012-K1639 | ||
| 13 | 04020-01228 | PIN | K1012-K1639 | |
| 14 | 01643-31232 | WASHER | K1640- | |
| 195-13-11230 | PLATE (KIT) | K1012-K1639 | ||
| 15 | 01010-61230 | BOLT | K1640-. | |
| 01010-51230 | BOLT | K1012-K1639 | ||
| 16 | 07040-10807 | PLUG | K1060-. | |
| \0\07040-00807 | PLUG | K1012-K1059 | ||
| 17 | 195-13-11240 | BEARING | K1012-. | |
| 18 | 195-13-11252 | PILOT | K1337-. | |
| \0\195-13-11251 | PILOT | K1012-K1336 | ||
| 19 | 195-13-11261 | PLATE | K1012-. | |
| 20 | 01010-51230 | BOLT | K1012-. | |
| 21 | 195-13-11271 | SHIM¤ 0.05MM (KIT) | K1012-K1336 | |
| 22 | 195-13-11281 | SHIM¤ 0.3MM (KIT) | K1012-K1336 | |
| 23 | 195-13-11291 | SHIM¤ 0.7MM (KIT) | K1012-K1336 | |
| 195-13-91510 | TURBINE ASS'Y | K1337-. | ||
| 195-13-11511 | TURBINE ASS'Y | K1012-K1336 | ||
| 24 | \6\ | TURBINE | K1337-. | |
| \6\ | TURBINE | K1012-K1336 | ||
| 25 | \6\ | BOSS | K1337-. | |
| \6\ | BOSS | K1012-K1336 | ||
| 26 | \6\ | PLATE | K1337-. | |
| \6\ | PLATE | K1012-K1336 | ||
| 27 | \6\ | RIVET | K1337-. | |
| \6\ | RIVET | K1012-K1336 | ||
| 28 | 195-13-11653 | SHAFT | K1337- | |
| 195-13-11652 | SHAFT | K1060-K1336 | ||
| 195-13-11651 | SHAFT | K1021-K1059 | ||
| 195-13-11650 | SHAFT | K1012-K1020 | ||
| 29 | 195-13-11691 | HOLDER | K1060- | |
| \0\195-13-11690 | HOLDER | K1012-K1059 | ||
| 30 | 195-13-11711 | PLATE (KIT) | K1060- | |
| \0\195-13-11710 | PLATE | K1012-K1059 | ||
| 31 | 195-13-11810 | BOLT | K1060-. | |
| 01010-51230 | BOLT | K1012-K1059 | ||
| 32 | 04066-00070 | RING | K1012-K1020 | |
| 33 | 04066-00075 | RING | K1012-. | |
| 34 | 195-13-11720 | RING | K1012-. | |
| 35 | 195-13-11730 | SPACER | K1012-. | |
| 36 | 195-13-11741 | SPACER | K1012-K1077 | |
| 37 | 195-13-11750 | SEAT | K1012-K1077 | |
| 37 | 195-13-11751 | SEAT | K1078-. | |
| 38 | 07000-32070 | O-RING (KIT) | K1337-. | |
| \0\07000-02070 | O-RING | K1012-K1336 | ||
| 39 | 06030-06315 | BEARING | K1012-. | |
| 40 | 195-13-11662 | COUPLING ASS'Y | K1337-. | |
| \0\195-13-11661 | COUPLING | K1012-K1336 | ||
| 41 | 07020-00001 | FITTING | K1012-. | |
| 42 | 175-13-22313 | STATOR | 1337-. | |
| 195-13-12111 | STATOR | K1012-K1336 | ||
| 43 | 195-13-12121 | RACE | K1012-. | |
| 44 | 195-13-12211 | PLATE (KIT) | K1012-. | |
| 45 | 01010-51030 | BOLT | K1012-. | |
| 46 | 195-13-12621 | SPACER | K1337-. | |
| 195-13-12620 | SPACER | K1012-K1336 | ||
| 47 | 195-13-12630 | SPACER | K1012-. | |
| 48 | 195-13-12523 | SHAFT | K1337-. | |
| 195-13-12510 | SHAFT ASS'Y | K1153-K1336 | ||
| 195-13-12522 | SHAFT | K1153-K1336 | ||
| 195-13-12530 | SLEEVE | K1153-K1336 | ||
| 195-13-12521 | SHAFT | K1012-K1152 | ||
| 49 | 195-13-12641 | NUT | K1012-. | |
| 50 | 01658-28823 | WASHER (KIT) | K1012-. | |
| 51 | 195-13-12711 | RING | K1039-. | |
| \0\195-13-12710 | RING | K1012-K1138 | ||
| 52 | 07000-65220 | O-RING (KIT) | K1337-. | |
| 07000-05210 | O-RING (KIT) | K1012-K1336 | ||
| 53 | 07000-65165 | O-RING (KIT) | K1337-. | |
| \0\07000-05165 | O-RING | K1012-K1336 | ||
| 54 | 01010-51235 | BOLT | K1012-. | |
| 55 | 01602-21236 | WASHER | K1012-. | |
| 56 | 195-13-12723 | COVER | K1337-. | |
| 195-13-12722 | COVER | K1012-K1336 | ||
| 57 | 07011-10090 | SEAL (KIT) | K1337-. | |
| \0\07011-00090 | SEAL | K1012-1336 | ||
| 58 | 01010-51235 | BOLT | K1012-. | |
| 59 | 01602-21236 | WASHER | K1012-. | |
| 60 | 195-13-12730 | SEAL (KIT) | K1012-. |
