| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 6162-63-8570 | Joint, Water | 511668- | |
| 2 | 6164-62-8241 | Gasket | 511668- | |
| 3 | 01252-31035 | Bolt, Hexagon Socket Head | 511668- | |
| 4 | 6164-62-8230 | Plate | 511668- | |
| 5 | 6164-62-8241 | Gasket | 511668- | |
| 6 | 01435-01020 | Bolt | 511668- | |
| 7 | 6245-61-6851 | Tube, Inlet | 511668- | |
| 8 | 07206-31014 | Bolt, Joint | 511668- | |
| 9 | 07003-01419 | Gasket | 511668- | |
| 10 | 6151-53-8280 | Clip | 511668- | |
| 11 | 01010-81055 | Bolt | 511668- | |
| 12 | 01643-31032 | Washer | 511668- | |
| 13 | 6144-81-6680 | Spacer | 511668- | |
| 14 | 6151-53-8280 | Clip | 511668- | |
| 15 | 6245-61-6860 | Tube, Return | 511668- | |
| 16 | 07206-31014 | Bolt, Joint | 511668- | |
| 17 | 07003-01419 | Gasket | 511668- | |
| 18 | 6151-53-8280 | Clip | 511668- | |
| 19 | 01010-81020 | Bolt | 511668- | |
| 20 | 01643-31032 | Washer | 511668- | |
| 21 | 6245-61-6880 | Bracket | 511668- | |
| 22 | 01435-01025 | Bolt | 511668- | |
| 23 | 6240-51-8340 | Clamp | 511668- | |
| 24 | 6240-51-8350 | Clamp | 511668- | |
| 25 | 01010-81040 | Bolt | 511668- | |
| 26 | 01643-31032 | Washer | 511668- | |
| 27 | 6245-61-7110 | Bracket | 511668- | |
| 28 | 01435-01025 | Bolt | 511668- | |
| 29 | 6245-61-6790 | Hose | 511668- | |
| 30 | 07281-00197 | Clamp | 511668- | |
| 31 | 6245-61-6870 | Tube, Return | 511668- | |
| 32 | 6127-71-5710 | Bolt, Joint | 511668- | |
| 33 | 07005-01412 | Seal, Washer | 511668- | |
| 34 | 07040-11612 | Plug | 511668- | |
| 35 | 07005-01612 | Seal, Washer | 511668- | |
| 36 | 6151-53-8280 | Clip | 511668- | |
| 37 | 01010-81030 | Bolt | 511668- | |
| 38 | 01643-31032 | Washer | 511668- | |
| 39 | 6245-61-7120 | Plate | 511668- | |
| 40 | 01435-01030 | Bolt | 511668- | |
| 41 | 419-15-17540 | Spacer | 511668- |
