| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 114-54-51680 | GUARD,FRONT | 42714- | |
| 04431-11000 | CLIP (WELDED) | 42714- | ||
| 04431-30000 | PLATE | 42714- | ||
| 2 | 113-C62-2660 | SHEET | 42714- | |
| 3 | 113-C62-2670 | SHEET | 42714- | |
| 4 | 113-C62-2680 | SHEET | 42714- | |
| 5 | 114-54-51660 | SHEET | 42714- | |
| 6 | 114-54-51670 | SHEET | 42714- | |
| 7 | 01010-81435 | BOLT | 42001- | |
| 8 | 01602-21442 | WASHER,SPRING | 42001- | |
| 9 | 114-54-51650 | COVER | 42714- | |
| 10 | 01010-81025 | BOLT | 42001- | |
| 11 | 01602-21030 | WASHER,SPRING | 42001- | |
| 12 | 07049-01418 | PLUG | 42001- | |
| 13 | 113-C62-2640 | GUARD,REAR | 42714- | |
| 04431-11000 | CLIP (WELDED) | 42714- | ||
| 04431-30000 | PLATE | 42714- | ||
| 14 | 113-A62-2370 | SEAT | 42714- | |
| 15 | 01010-81435 | BOLT | 42001- | |
| 16 | 01602-21442 | WASHER,SPRING | 42001- | |
| 17 | 01643-31445 | WASHER | 42001- | |
| 18 | 113-54-25250 | COVER | 42001- | |
| 19 | 01010-81025 | BOLT | 42001- | |
| 20 | 01602-21030 | WASHER,SPRING | 42001- | |
| 21 | 111-944-1110 | HOOK | 42001- | |
| 22 | 01010-81450 | BOLT | 42001- | |
| 23 | 01643-31445 | WASHER | 42001- |
