| Item | Part No. | Part Name | Qty | Serial No. |
| 423-947-1101 | TANK ASS'Y | 70001- | ||
| 1 | 423-947-1110 | PUMP ASS'Y | 70001- | |
| 2 | 423-947-1121 | TANK | 70001- | |
| 3 | 423-947-2150 | CAP | 70001- | |
| 4 | 418-07-36130 | HOSE | 70001- | |
| 5 | 08034-20519 | BAND | 70001- | |
| 6 | 418-07-36151 | HOSE | 70001- | |
| 7 | 04435-50810 | CLIP | 70001- | |
| 8 | 01010-81025 | BOLT | 70001- | |
| 9 | 01643-31032 | WASHER | 70001- | |
| 10 | 419-944-3210 | WIRING HARNESS | 70001- | |
| 11 | 04434-51012 | CLIP | 70001- | |
| 12 | 418-07-36120 | BRACKET | 70001- | |
| 13 | 01010-81020 | BOLT | 70001- | |
| 14 | 01643-31032 | WASHER | 70001- | |
| 15 | 04435-50812 | CLIP | 70001- |
