| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 421-06-21251 | WIRING HARNESS,REAR FRAME | 53302- | |
| 1 | 421-06-21130 | WIRING HARNESS,REAR FRAME | 53001-53301 | |
| 1 | 08020-10000 | DIODE | 53001- | |
| 2 | 01435-01020 | BOLT | 53001- | |
| 3 | 421-06-21260 | BRACKET | 53302- | |
| 3 | 08053-01510 | CLIP | 53302- | |
| 3 | 08053-00910 | CLIP | 53302- | |
| 3 | 421-06-22660 | BRACKET | 53001-53301 | |
| 3 | 08053-00912 | CLIP | 53001-53301 | |
| 3 | 08053-01510 | CLIP | 53001-53301 | |
| 3 | 01435-01220 | BOLT | 53001-53999 | |
| 4 | 04434-53412 | CLIP | 53001- | |
| 5 | 01435-01016 | BOLT | 53001- | |
| 6 | 04434-51710 | CLIP | 53001- | |
| 7 | 417-54-15541 | SPACER | 53001- | |
| 8 | 01435-01055 | BOLT | 53001- | |
| 9 | 04434-52712 | CLIP | 53001- | |
| 10 | 01435-01016 | BOLT | 53001- | |
| 11 | 08052-12411 | CLIP | 53001- | |
| 12 | 01435-01016 | BOLT | 53001- | |
| 13 | 04434-51710 | CLIP | 53001- | |
| 14 | 01435-01016 | BOLT | 53001- | |
| 15 | 04434-51010 | CLIP | 53001- | |
| 16 | 01435-01016 | BOLT | 53001- |
