| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 154-06-74112 | WIRING HARNESS | 11004- | |
| 1 | 154-06-74111 | WIRING HARNESS | 11001-11003 | |
| 2 | 04434-53212 | CLIP | 11001- | |
| 3 | 01010-81230 | BOLT | 11001- | |
| 4 | 01643-31232 | WASHER | 11001- | |
| 5 | 04434-51012 | CLIP | 11001- | |
| 6 | 04434-51010 | CLIP | 11001- | |
| 7 | 01010-81230 | BOLT | 11001- | |
| 8 | 01643-31232 | WASHER | 11001- | |
| 9 | 198-49-46260 | BRACKET | 11001- | |
| 10 | 01010-81655 | BOLT | 11001- | |
| 11 | 04434-52512 | CLIP | 11001- | |
| 12 | 04434-51712 | CLIP | 11001- | |
| 13 | 01010-81230 | BOLT | 11001- | |
| 14 | 01643-31232 | WASHER | 11001- | |
| 15 | 17M-49-42331 | BRACKET | 11001- | |
| 16 | 154-06-71231 | BRACKET | 11001- | |
| 17 | 01010-81655 | BOLT | 11001- | |
| 18 | 01010-81220 | BOLT | 11001- | |
| 19 | 01643-31232 | WASHER | 11001- | |
| 20 | 08193-21012 | CLIP | 11001- | |
| 21 | 08034-20519 | BAND | 11001- | |
| 22 | 154-06-74550 | BRACKET | 11001- | |
| 23 | 04434-50810 | CLIP | 11001- | |
| 24 | 01010-81016 | BOLT | 11001- | |
| 25 | 01643-31032 | WASHER | 11001- | |
| 26 | 7861-93-3320 | SENSOR | 11001- | |
| 27 | 08193-21012 | CLIP | 11001- | |
| 28 | 7861-93-1650 | SENSOR | 11001- | |
| 28 | 07002-11823 | O-RING | 11001- | |
| 29 | 04434-51012 | CLIP | 11001- | |
| 30 | 195-06-41930 | BRACKET | 11001- | |
| 31 | 04434-50610 | CLIP | 11001- | |
| 32 | 01010-81020 | BOLT | 11001- | |
| 33 | 01643-31032 | WASHER | 11001- |
